A hardware wallet's primary defense against physical side-channel extraction (voltage glitching, laser fault injection, and power analysis) is its Secure Element (SE). However, historical Secure Elements required strict manufacturer Non-Disclosure Agreements (NDAs), forcing security engineers to choose between physical chip hardening and open-source firmware auditability. Here is how modern 2026 architectures solve that trade-off.

4 Competing Cryptographic Storage Architectures Compared

1. Dual Independent Secure Elements

Coldcard Mk4 & Coldcard Q

Splits critical secret material across two chips from competing semiconductor foundries—Microchip ATECC608B and Maxim DS28C36B—plus the main STM32 MCU. An attacker must compromise all three independent silicon dies simultaneously.

2. NDA-Free CC EAL6+ Open-Source SE

Trezor Safe 5, Trezor Safe 3 & BitBox02

Utilizes the Infineon Optiga Trust M V3 (CC EAL6+) chip without proprietary firmware black boxes, allowing 100% GPLv3/Apache-2.0 open-source firmware reproducibility alongside hardware PIN brute-force throttling.

3. Monolithic ST33 EAL6+ Direct-Screen Drive

Ledger Flex & Ledger Stax

The STMicroelectronics ST33K1M5 (CC EAL6+) Secure Element drives the E Ink display directly without passing display buffers through an unverified MCU, though the internal BOLOS operating system remains under NDA.

4. Stateless RAM & Blind Oracle

SeedSigner & Blockstream Jade Plus

SeedSigner stores zero keys on flash memory (wiping RAM when unplugged), while Blockstream Jade Plus uses a server-assisted Blind Oracle split-key decryption model that requires zero NDA silicon.
